Name: GOLDEN Mono Block AC/DC PUMPS
SKU: 3919
Availability: InStock

GOLDEN Mono Block AC/DC PUMPS

Range of Pressure Master Switches

Price range: ₨ 96,250 through ₨ 140,000

Download Instruction Mannual

Function

Golden Mono Block AC DC Pumps are high capacity surface water pumps designed for heavy duty agricultural commercial and industrial applications in Pakistan. These pumps are engineered to deliver powerful water discharge with maximum efficiency and stable performance. The mono block design integrates motor and pump into a single compact unit which ensures strong alignment reduced vibration and reliable long term operation.

This product range includes models from 1500 Watts to 3000 Watts which makes it suitable for medium to large scale water transfer requirements. Golden Mono Block Pumps are available in both AC DC and DC configurations which allows flexibility for solar powered systems as well as conventional electric supply. The pumps are designed to handle high flow rate output reaching up to 1333 liters per minute depending on model capacity.

With strong hydraulic performance and stable voltage compatibility these pumps provide consistent water pressure for continuous duty operation. Golden Mono Block AC DC Pumps are built for users who require powerful water lifting with efficient energy utilization.

Application

Golden Mono Block AC DC Pumps are ideal for agricultural irrigation systems including canal water lifting tube well transfer and sprinkler irrigation. Farmers across Pakistan can use these pumps for large farms orchards and crop fields where high water flow is required. The availability of AC DC voltage compatibility makes these pumps suitable for solar powered irrigation systems which helps reduce electricity costs.

For commercial use these pumps are suitable for water supply in housing projects commercial buildings livestock farms and industrial facilities. They are capable of transferring large volumes of water efficiently which makes them practical for water circulation systems storage tank filling and drainage applications.

In industrial environments Golden Mono Block Pumps are used for water transfer cooling systems and process water supply. Their strong construction and high discharge capacity ensure reliable operation even under demanding conditions. Different size options including 3 inch by 3 inch 4 inch by 4 inch and 5 inch by 5 inch allow compatibility with various pipeline systems.

Pump Construction

Golden Mono Block AC DC Pumps are manufactured using heavy duty materials to ensure durability and long service life. The mono block construction combines the motor and pump into a single rigid unit which improves mechanical stability and reduces maintenance requirements. This design minimizes alignment issues and enhances overall efficiency.

The pump casing is designed to handle high pressure and continuous water flow. Internal hydraulic components are optimized to maximize discharge capacity while maintaining smooth water movement. The motor is engineered for stable voltage operation with DC voltage range up to 432 V and AC voltage range up to 282 V depending on model.

The shaft and impeller assembly are built to withstand continuous load and high flow performance. Strong sealing systems protect internal components from water leakage and external damage. These pumps are designed for surface installation and provide easy maintenance access which makes them practical for long term use in agricultural and industrial setups.

Pump Performance Data

Golden Mono Block AC DC Pumps are available in the following performance range:

Power Range 1500 Watts to 3000 Watts
Pump Size Options 3 inch x 3 inch 4 inch x 4 inch 5 inch x 5 inch
DC Voltage Range 80 to 432 V
AC Voltage Range 85 to 282 V
Maximum Flow Rate 416 LPM to 1333 LPM depending on model
Maximum Head Range 3 meters to 20 meters depending on model
Retail Price Range 96,250 PKR to 140,000 PKR

The 1500W model delivers strong flow performance up to 833 LPM with head capacity up to 18 meters. The 2200W model provides improved discharge capacity reaching up to 750 LPM with reliable head performance. The 3000W DC model offers maximum flow output up to 1333 LPM and head up to 20 meters which makes it ideal for heavy duty irrigation and industrial water transfer.
